Product name：12W-18W EU Power adapter
1. Brand name: COOLWOLF
2. Input pins: EU
3. Input voltage range: 90~264V (Wide voltage)
4. Output voltage range: 3~24V
5. Output current range: 100~ 3000mA
6. Energy efficiency: V, VI
7. Output DC interface: 5.5*2.5/5.5*2.1/4.0*1.7/3.5*1.35/2.5*0.7mm
8. Output DC line length: 1.5m (Customizable)
9. Color: Black and White
10. Certification: CE/GS/ROHS
Details
Product name: Power adapter
Input voltage: 90V ~ 264V(wide voltage)
Voltage frequency: 50 ~ 60Hz
Output voltage: 3V~ 24V
Output power: 12~18W
Output DC connectors: 5.5 * 2.5, 5.5 * 2.1, 4.0 * 1.7, 3.5 * 1.35, 2.5 * 0.7 mm, etc..
Efficiency: 80-85 %
Operating temperature: 0 °C + 50 °C
Storage temperature: -20 °C + 80 °C
Product aging: 100 % full load aging
Output Wave &; Noise: 80-120mV
Protection function: Short circuit protection, overpressure protection, overload protection 105 % -150 % rated power, automatic protection
Insulation strength: Input-output AC AC 3000V/10mA, 1 minute
Insulation resistance: Input-output ≥ 500MΩ Input-housing ≥ 500MΩ
Applicable products: Small household appliances, laptops, tablets, lamps and lanterns, security products, beauty instruments, security products, medical equipment and so on.
